ALL SIZES SHOWN BELOW ARE STANDARD SIZES. LARGER SIZES ARE ALSO AVAILABLE:
The heart of the system is an air compressor sized to fully meet your job requirements. Capacity is sufficient to operate all
pumps (grease, oil, fuel, water). The compressed air supply may also be used to operate air tools and washing equipment,
inflate tyres, de-dust radiators and clean air filters.
pumps (grease, oil, fuel, water). The compressed air supply may also be used to operate air tools and washing equipment,
inflate tyres, de-dust radiators and clean air filters.
|
NIPPLES
AF 4004 - ¼” BSPT MALE AF 4006 - 3/8” BSPT MALE
NIPPLES
AF 4014 - ¼” BSPT FEMALEAF 4016 - 3/8” BSPT FEMALE
|
AF 203: 4.76mm TUBE ID - 1/8” BSPT MALE THREAD
AF 204: 6.35mm TUBE ID - 1/8” BSPT MALE THREAD AF 205: 7.94mm TUBE ID - 1/8” BSPT MALE THREAD AF 206: 9.53mm TUBE ID - 1/8” BSPT MALE THREAD AF 208: 12.7mm TUBE ID - 1/8” BSPT MALE THREAD AF 404: 6.35mm TUBE ID - 1/4” BSPT MALE THREAD AF 405: 7.94mm TUBE ID - 1/4” BSPT MALE THREAD AF 406: 9.53mm TUBE ID - 1/4” BSPT MALE THREAD AF 408: 12.7mm TUBE ID - 1/4” BSPT MALE THREAD AF 604: 6.35mm TUBE ID - 3/8” BSPT MALE THREAD AF 605: 8.00mm TUBE ID - 3/8” BSPT MALE THREAD AF 606: 9.53mm TUBE ID - 3/8” BSPT MALE THREAD AF 608: 12.7mm TUBE ID - 3/8” BSPT MALE THREAD AF 806: 9.53mm TUBE ID - 1/4” BSPT MALE THREAD AF 808: 12.7mm TUBE ID - 1/4” BSPT MALE THREAD |
QUICK COUPLINGS
IE-4-QC/210 - ¼” BSP FEMALE
SPLICERS
AF 20 - 12.70mm TUBE ID AF 21 - 12.70mm TUBE ID AF 22 - 12.70mm TUBE ID
CONNECTORS
AF 4024 - ¼” HOSE CONNECTOR AF 4025 - 5/16” HOSE CONNECTOR AF 4026 - 3/8” HOSE CONNECTOR
|
