To fit container size:

15kg

Pressure ratio:

50:1

Output pressure:

Up to 41400 kPa (Bar 414; PSI 6000)

Delivery up to No. 2 Grease:

700g per minute

Maximum Air Pressure:

120 PSI (8.4 Bar; 840 kPa)

Air Consumption:

0,340m3 per minute (12CFM)

W28A = Pump only

W28B = Pump; lid; follow plate; 3m grease outlet hose; grease control handle; z-swivel

W28C = Pump, lid, follow plate; 3m grease outlet hose; grease control handle; z-swivel; trolley

To fit container size:

50kg

Pressure ratio:

50:1

Output pressure:

Up to 41400 kPa (Bar 414; PSI 6000)

Delivery up to No. 2 Grease:

700g per minute

Maximum Air Pressure:

120 PSI (8.4 Bar; 840kPa)

Air Consumption:

0,340m3 per minute (12CFM)

W29A = Pump only

W29B = Pump; lid; follow plate; 3m grease outlet hose; grease control handle; z-swivel

W29C = Pump, lid, follow plate; 3m grease outlet hose; grease control handle; z-swivel; trolley

To fit container size:

180kg

Pressure ratio:

50:1

Output pressure:

Up to 41400 kPa (Bar 414; PSI 6000)

Delivery up to No. 2 Grease:

700g per minute

Maximum Air Pressure:

120 PSI (8.4 Bar; 840 kPa)

Air Consumption:

0,340m3 per minute (12CFM)

W30A = Pump only

W30B = Pump; lid; follow plate; 3m grease outlet hose; grease control handle; z-swivel

W30C = Pump, lid, follow plate; 3m grease outlet hose; grease control handle; z-swivel; trolley

To fit container size:

180kg (other sizes can be made on request)

Applications: This unit is used in conjunction with centralised lube systems
and any applications where the grease/oil must not be contaminated
in any way - also prevents grease/oil pumps from getting dirt in them
during change over of products.

(Ram can be bought separately)

Complete with: Pump; lid; regulator; control valve; 1.5m hose; Ram

To fit container size: 210 litre

Model IE/L/W12A:  1:1 Ratio air operated transfer pump for 2– litre drums for the transfer of liquids (parafin, diesel, petrol, oil. aviation fuel etc) from original drums. Complete with pump and bung adaptor.

Model IE/L/W12B:  3:1 Ratio air operated transfer pump for 2– litre drums for the transfer of liquids (parafin, diesel, petrol, oil. aviation fuel etc) from original drums to one or more outlet points through permanent pipe lines with hose reels and meters in line.. Complete with pump and bung adaptor.

Model

Ratio

Del lit/min

IE/L/W12A

1:1

40

Model IE/L/W12C:  1:1 Ratio air operated stub pump for wall or bulk tank mounting (specifica-tions same as W12A). Pump only - wall bracket optional.

IE/L/W12B

3:1

15

IE/L/W12C

1:1

40

Model IE/L/W12D:  3:1 Ratio air operated stub pump for wall or bulk tank mounting (specifica-tions same as W12B). Pump only - wall bracket optional.

IE/L/W12D

3:1

15

To fit container size:

210 litre

Input pressure::

700 kPa (7 Bar)

Output pressure:

3,5 MPA (35 Bar)

Delivery:

SAE 30 - 10 litres per minute

This pump is used where you have long delivery lines with hose reels

and meters in-line. Also available in a stub pump.
